Basler A102f User Manual

Introduction
1-2 BASLER A102
f
DRAFT
1.2 Performance Specifications
Specification A102f A102fc
Sensor Type Sony ICX-285 Progressive Scan CCD Sensor
Pixels 1392 (H) × 1040 (V) 1388 (H) x 1038 (V)
Pixel Size 6.45 µm (H) × 6.45 µm (V)
Mono / Color Mono Color
Anti-blooming Yes
Max. Frame Rate
(at full resolution)
15.1 frames/s (in 8 bit output modes)
11.3 frames/s (in 16 bit output modes)
Video Output Formats
Mono 8, 8 bits/pixel
Mono 16, 16 bits per pixel
(12 bits effective)
Mono 8, 8 bits/pixel
Raw 8, 8 bits/pixel
Raw 16, 16 bits/pixel
(12 bits effective)
YUV 4:2:2, 16 bits/pixel average
Gain and Brightness
Programmable via IEEE 1394 bus
Exposure Time Control Programmable via IEEE 1394 bus
Synchronization External via External Trigger signal
Power Requirements +8.0 to +36.0 VDC (+12 VDC nominal), < 1% ripple
3.5 W max @ 12 VDC
supplied via 1394 cable
I/O Electrical
Characteristics
Inputs: opto-isolated, 5 VDC nominal, 10 mA nominal
Outputs: opto-isolated, 2 to 35 VDC maximum forward voltage, 100
mA max collector current
(See Sections 2.5.1 and 2.5.2 for more details.)
Max. Cable Lengths
1394: 4.5 m
I/O: 10 m
(See Section 2.2 for more details.)
Lens Adapter
C-mount
Housing Size
(L x W x H)
without lens adapter: 31.5 mm x 62 mm x 62 mm
with c-mount adapter: 67.3 mm x 62 mm x 62 mm
Weight
~ 240 g
Conformity CE, FCC
Table 1-1: A102f Performance Specifications
