6.7 Smart Features on the A102f
6.7.1 Extended Data Stream
The extended data stream feature has two functions:
• When it is enabled, information such as image height, image width, and AOI size is added to
the basic pixel data for each image.
• It must be enabled before you can use any other smart feature that adds information to the
image data stream.
With the extended data stream feature enabled, the basic pixel data for each image and the added
information such as the image height and width are included in an “extended data chunk”. Refer
to the extended data chunk layout below for a complete description of the information included in
the extended data chunk.
Control and Status Register for the Extended Data Stream Feature
Extended Data Chunk Layout
L
The extended data stream feature must be enabled in order to use any of the other
smart feature that adds information to the image data stream. Disabling the extended
data stream feature switches off all smart features that add information to the image
data stream.
The extended data stream feature and any other smart features which add informa-
tion to the image data stream will only work when the camera is set for video format 7.
Name Extended Data Stream
Address See “Determining the Address of Smart Features CSRs” on page 6-4.
CSR GUID 4E7ABCB0 - 1B84 - 11D8 - 9651 - 00105A5BAE55
Field Bit Description
Presence Inq
(Read only)
[0] Presence of this feature
0: Not Available 1: Available
---- [1 ... 30] Reserved
Enable
(Read / write)
[31] Enable / Disable this feature
0: Disable 1: Enable
Position Name Description
0 Pixel Data
[ K Bytes ]
The pixel data from the captured image
KGap
[ M Bytes ]
For technical reasons, there might be a gap between the
pixel data and the other data in the extended image data.
