Basler A102f User Manual

Smart Features
6-10 BASLER A102
f
DRAFT
K + M Stride
[ 4 Bytes ]
Signed integer. Indicates the number of bytes needed to
advance from the beginning of one row in an image to the
beginning of the next row.
K + M + 4 Reserved
[ 3 Bytes ]
-----
K + M + 7 Data Depth
[ 1 Byte ]
Effective data depth in bits of the pixels in the image.
K + M + 8 Top
[ 2 Bytes ]
Y coordinate of the top left corner of the current area of in-
terest (AOI).
K + M + 10 Left
[ 2 Bytes ]
X coordinate of the top left corner of the current AOI.
K + M + 12 Height
[ 2 Bytes ]
Height in pixels of the current AOI.
K + M + 14 Width
[ 2 Bytes ]
Width in pixels of the current AOI.
K + M + 16 Reserved
[ 3 Bytes ]
-----
K + M + 19 Color Coding ID
[ 1 Byte ]
Color coding ID which describes the pixel data format. See
Sections 3.12.2 and 3.13.2 and pages 4-28 and 4-29.
K + M + 20 Reserved
[ 3 Bytes ]
-----
K + M + 23 Color Filter ID
[ 1 Byte ]
For color cameras, describes the orientation of the color fil-
ter to the current AOI. See Section 3.8.2 and page 4-32.
K + M + 24 Chunk GUID
[ 16 Bytes ]
94ED7C88 - 1C0F - 11D8 - 82E0 - 00105A5BAE55
K + M + 40 Chunk Length
[ 4 Bytes ]
This chunk’s total length in bytes.
K + M + 44 Inverted Chunk Length
[ 4 Bytes ]
The bitwise complement of the chunk length.
