Basler A102f User Manual

Basic Operation & Standard Features
BASLER A102
f 3-37
DRAFT
3.14 Error Flags
A102f cameras support the following error flags:
• Error flags that indicate whether the current trigger, shutter, gain, brightness, and white bal-
ance settings are outside the specified range of allowed values. These error flags are set in
the Trigger, Shutter, Gain, Brightness and White Balance fields of the Feature Control Error
Status High register (see page 4-25).
• An error flag that indicates whether the current combination of the following settings is
acceptable to the camera:
• Video format
•Mode
• Frame rate
• ISO speed
This error flag is available for Format 2 only and is set in the VMode Error Status register
(see page 4-18).
• An error flag that indicates whether the current combination of the following settings is
acceptable to the camera:
• Image position
• Image size
• Color coding ID
• ISO speed
This error flag is available for Format 7 only.
If you are operating the camera in Format 7, Mode 0, the flag is set in the Error Flag 1 field of
the Value Setting register for Format 7, Mode 0 (see page 4-33).
If you are operating the camera in Format 7, Mode 1, the flag is set in the Error Flag 1 field of
the Value Setting register for Format 7, Mode 1 (see page 4-40).
• An error flag that indicates whether the current bytes per packet setting is acceptable to the
camera.
This error flag is available for Format 7 only.
If you are operating the camera in Format 7, Mode 0, the flag is set in the Error Flag 2 field of
the Value Setting register for Format 7, Mode 0 (see page 4-33).
If you are operating the camera in Format 7, Mode 1, the flag is set in the Error Flag 2 field of
the Value Setting register for Format 7, Mode 1 (see page 4-40).
L
The error flag registers are defined in version 1.31 of the IIDC specification.
