Basler A102f User Manual

Configuring the Camera
BASLER A102
f 4-5
DRAFT
4.4.1.4 Inquiry Registers for Video Frame Rates
Each bit in the video frame rates inquiry register indicates the availability of a specific video format,
mode, frame rate combination (e.g., Format 0, Mode 0, Frame Rate 0).
0 = format not available 1 = format available
Register Name: Video Frame Rate Inquiry for Format 2, Mode 0
Offset from Base Address: 0x240
Field Bit Description A102f
Value
A102fc
Value
Frame Rate 0
0 1.875 fps standard frame rate 0 0
Frame Rate 1 1 3.75 fps standard frame rate 0 0
Frame Rate 2 2 7.5 fps standard frame rate 0 1
Frame Rate 3 3 15 fps standard frame rate 0 0
Frame Rate 4 4 30 fps standard frame rate 0 0
Frame Rate 5 5 60 fps standard frame rate 0 0
Frame Rate 6 6 Reserved --- ---
Frame Rate 7 7 Reserved --- ---
--- 8 ... 31 Reserved --- ---
Register Name: Video Frame Rate Inquiry for Format 2, Mode 2
Offset from Base Address: 0x248
Field Bit Description A102f
Value
A102fc
Value
Frame Rate 0
0 1.875 fps standard frame rate 0 0
Frame Rate 1 1 3.75 fps standard frame rate 0 0
Frame Rate 2 2 7.5 fps standard frame rate 0 0
Frame Rate 3 3 15 fps standard frame rate 1 1
Frame Rate 4
4 30 fps standard frame rate 0 0
Frame Rate 5 5 60 fps standard frame rate 0 0
Frame Rate 6 6 120 fps standard frame rate 0 0
Frame Rate 7 7 Reserved --- ---
---- 8 ... 31 Reserved --- ---
