4.4.1.3 Inquiry Registers for Video Modes
Each bit in the video mode inquiry register indicates the availability of a specific video format and
mode combination (e.g., Format 0, Mode 0).
0 = not available 1 = available
Register Name: Video Mode Inquiry for Format 2
Offset from Base Address: 0x188
Field Bit Description A102f
Value
A102fc
Value
Mode 0
0 1280 x 960, YUV 4:2:2, 16 bits/pixel 0 1
Mode 1 1 1280 x 960, RGB, 24 bits/pixel 0 0
Mode 2 2 1280 x 960, Y Mono, 8 bits/pixel 1 1
Mode 3 3 1600 x 1200, YUV 4:2:2, 16 bits/pixel 0 0
Mode 4 4 1600 x 1200, RGB, 24 bits/pixel 0 0
Mode 5 5 1600 x 1200, Y Mono, 8 bits/pixel 0 0
Mode 6 6 1280 x 960, Y Mono, 16 bits/pixel 1 0
Mode 7 7 1600 x 1200, Y Mono, 16 bits/pixel 0 0
--- 8 ... 31 Reserved --- ---
Register Name: Video Mode Inquiry for Format 7
Offset from Base Address: 0x19C
Field Bit Description A102f
Value
A102fc
Value
Mode 0
0 Format 7, Mode 0 1 1
Mode 1 1 Format 7, Mode 1 0 1
Mode 2 2 Format 7, Mode 2 0 0
Mode 3 3 Format 7, Mode 3 0 0
Mode 4 4 Format 7, Mode 4 0 0
Mode 5
5 Format 7, Mode 5 0 0
Mode 6 6 Format 7, Mode 6 0 0
Mode 7 7 Format 7, Mode 7 0 0
--- 8 ... 31 Reserved 0 0
