Configuring the Camera
4-46 BASLER A102
f
DRAFT
4.4.3 Advanced Features Registers
The base address for all advanced features registers is:
Bus ID, Node ID, FFFF F2F0 0000
The first eight quadlets of the advanced features register space is designated as the advanced
features “Access Control Register” as described in the table below.
Values are stated in decimal format except when marked 0x. Values marked as 0x (e.g., 0x123)
are in hexadecimal format. Bit 0 in each register is the most significant bit.
On the A102
f and A102fc, all advanced features registers, including the Access Control register,
have been made part of Basler’s Smart Features Framework (SFF). See Section 6 for a detailed
explanation of using the SFF framework to access advanced features. (Section 6.5.1 contains
specific information about using the Access Control register.)
Register Name: Special Features Access Control Register
Offset from Base Address: 0x000
Field Bit Description
Feature ID High 0 ... 31 On the A102f and A102fc, the value for Feature ID High field is:
0x0030 533B
Feature ID Low
32 ... 47 On the A102f and A102fc, the value for Feature ID Low field is:
0x73C3
0xF
48 ... 51 This value for this field always 0xF.
Time Out 52 ... 63 On the A102f and A102fc, the value for Time Out field is:
0x000
