Image Data Formats & Structures
5-2 BASLER A102
f
DRAFT
5.2 Packet Payload Charts for Standard Format, Mode
and Frame Rate Combinations on A102f Cameras
The following charts describe the packet payload for each standard format/mode/framerate
combination available on the A102f or the A102fc. This information is especially useful when
calculating a camera’s bandwidth usage.
5.2.1 Format 2, Mode 0
( 1280 x 960, YUV 4:2:2, 16 bits/pixel avg )
5.2.2 Format 2, Mode 2
( 1280 x 960, Y Mono, 8 bits/pixel )
5.2.3 Format 2, Mode 6
( 1280 x 960, Y Mono, 16 bits/pixel )
Frame Rate 7.5 fps
Lines per Packet 1/2
Pixels per Packet 640
Bytes per Packet 1280
Frame Rate 15 fps
Lines per Packet 2
Pixels per Packet 2560
Bytes per Packet 2560
Frame Rate 7.5 fps
Lines per Packet 1
Pixels per Packet 1280
Bytes per Packet 2560
