Basler A102f - Inquiry Registers for Format 7 CSR Offsets

Configuring the Camera
4-6 BASLER A102
f
DRAFT
4.4.1.5 Inquiry Registers for Format 7 CSR Offsets
Register Name: Video Frame Rate Inquiry for Format 2, Mode 6
Offset from Base Address: 0x258
Field Bit Description A102f
Value
A102fc
Value
Frame Rate 0
0 1.875 fps standard frame rate 0 0
Frame Rate 1 1 3.75 fps standard frame rate 0 0
Frame Rate 2 2 7.5 fps standard frame rate 1 0
Frame Rate 3 3 15 fps standard frame rate 0 0
Frame Rate 4 4 30 fps standard frame rate 0 0
Frame Rate 5 5 60 fps standard frame rate 0 0
Frame Rate 6 6 Reserved --- ---
Frame Rate 7 7 Reserved --- ---
--- 8 ... 31 Reserved --- ---
Register Name: Video CSR Inquiry for Format 7, Mode 0
Offset from Base Address: 0x2E0
Field Bit Description
Mode 0 0 ... 31 Indicates the quadlet offset from the base address of the initial register
space for the Format 7, Mode 0 Control and Status Register (CSR).
(The A102f and A102fc support Format 7, Mode 0)
Register Name: Video CSR Inquiry for Format 7, Mode 1
Offset from Base Address: 0x2E4
Field Bit Description
Mode 1 0 ... 31 Indicates the quadlet offset from the base address of the initial register
space for the Format 7, Mode 1 Control and Status Register (CSR).
(The A102fc supports Format 7, Mode 1)
