Smart Features
BASLER A102
f 6-33
DRAFT
6.7.12 Startup Memory Channel
As described in Section 3.15, A102f cameras include four memory channels that can be used to
store camera configuration sets. Memory channel 0 contains a factory configuration set. Channels
1, 2 and 3 can be used to store user created configuration sets. The startup memory channel
smart feature lets you designate a memory channel and when the camera is powered on or reset,
the contents of the designated channel will be copied into the work set in the camera’s volatile
memory.
To designate a startup memory channel, write a value to the Channel field of the Startup Memory
Channel CSR.
Control and Status Register for the Startup Memory Channel Feature
L
You can only designate memory channel 1, 2 or 3 as the startup chanel if you have
previously saved a configuration set into the designated channel. You cannot use an
empty memory channel as the startup channel. See Section 3.15.
The startup memory channel smart feature does not add information to the image
data stream and can be accessed even when the extended data stream feature (see
Section 6.7.1) is disabled.
The startup memory channel smart feature is always enabled regardless of the video
format.
Name Startup Memory Channel
Address See “Determining the Address of Smart Features CSRs” on page 6-4.
CSR GUID 93A06C5C - 87BF - 11D8 - 86DD - 00105A5BAE55
Position Field Bit Description
0 Presence Inq
(Read only)
[0] Presence of this feature
0: Not Available 1: Available
----- [1 ... 27] Reserved
Channel [28 ... 31] Selects a memory channel. At camera power on or re-
set, the selected channel will be copied into the cam-
era’s work configuration set.
0: Channel 0 (Factory set)
1: Channel1
2: Channel 2
3: Channel 3
Default = 0
