Name Output Port 1 Configuration
Address See “Determining the Address of Smart Features CSRs” on page 6-4.
CSR GUID 949D820A - 4513 - 11D8 - 9EB1 - 00105A5BAE55
Position Field Bit Description
0 Same as port 0.
4 Same as port 0.
8 Same as port 0.
12 Same as port 0.
16 Same as port 0.
20 Same as port 0.
Name Output Port 2 Configuration
Address See “Determining the Address of Smart Features CSRs” on page 6-4.
CSR GUID C14E5072 - 4513 - 11D8 - 81F3 - 00105A5BAE55
Position Field Bit Description
0 Same as port 0.
4 Same as port 0.
8 Same as port 0.
12 Same as port 0.
16 Same as port 0.
20 Same as port 0.
Name Output Port 3 Configuration
Address See “Determining the Address of Smart Features CSRs” on page 6-4.
CSR GUID E79233CA - 4513 - 11D8 - 9B9A - 00105A5BAE55
Position Field Bit Description
0 Same as port 0.
4 Same as port 0.
8 Same as port 0.
12 Same as port 0.
16 Same as port 0.
20 Same as port 0.
