Control and Status Registers for the Output Port Configuration Feature
Name Output Port 0 Configuration
Address See “Determining the Address of Smart Features CSRs” on page 6-4.
CSR GUID 5A889D7E - 41E5 - 11D8 - 845B - 00105A5BAE55
Position Field Bit Description
0 Presence Inq
(Read only)
[0] Presence of the output port 0 configuration feature
0: Not Available 1: Available
Monitor Inq
(Read only)
[1] Presence of the monitor field
0: Not Available 1: Available
Invert Inq
(Read only)
[2] Presence of the invert field
0: Not Available 1: Available
User Setting Inq
(Read only)
[3] Presence of the user setting field
0: Not Available 1: Available
----- [4 ... 26] Reserved
Source Select
(Read / write)
[27 ... 31] Sets the source signal for output port 0:
0: Integrate Enabled signal
1: Trigger Ready signal
3: User set (state can be set with the User Setting
field described below)
4: Strobe
4 Source Select Inq
(Read only)
[0 ... 31] If bit n is set, then value n is valid for use in the
Source Select field. For example, if bit 0 is set, then
0 is a valid value for use in the Source Select field.
If bit 1 is set, then 1 is a valid value for use in the
Source Select field. Etc.
8 ----- [0 ... 30] Reserved
Monitor
(Read only)
[31] Shows the current state of the output:
0: Low (non-conducting)
1: High (conducting)
12 ----- [0 ... 30] Reserved
Invert
(Read / write)
[31] Enables signal inversion:
0: Do not invert
1: Invert
16 ----- [0 ... 30] Reserved
User Setting
(Read / write)
[31] If the Source Select field is set to “user set”, this field
sets the state of the output:
0: Low (non-conducting)
1: High (conducting)
(Sets the state of the output before the inverter.)
20 ----- [0 ... 31] Reserved
