Camera Interface
2-2 BASLER A102
f
DRAFT
2.1.2 Pin Assignments
The IEEE 1394 socket is used to supply power to the camera and to interface video data and
control signals. The pin assignments for the socket are shown in Table 2-1.
The RJ-45 jack is used to access the four physical input ports and four physical output ports on
the camera. The pin assignments for the jack are shown in Table 2-2.
Pin Signal
1 Power Input (+8.0 to +36.0 VDC)
2 DC Gnd
3 TPB -
4 TPB +
5 TPA -
6 TPA +
Table 2-1: Pin Assignments for the IEEE 1394 Socket
Pin Designation
1 Output Port 3 -
2 Output Port 2 -
3 Output Port 1-
4
Output Port 0 -
5 Input Port 0 +
6 In Gnd Comm
7 Out VCC Comm
8 Input Port 2 +
9
Input Port 1 +
10 Input Port 3 +
Table 2-2: Pin Assignments for the RJ-45 jack
