Basler A102f User Manual

Smart Features
BASLER A102
f 6-25
DRAFT
Control and Status Register for the Lookup Table Feature
Name Lookup Table
Address See “Determining the Address of Smart Features CSRs” on page 6-4.
CSR GUID B28C667C - DF9D - 11D7 - 8693 - 000C6E0BD1B0
Position Field Bit Description
0 Presence Inq
(Read only)
[0] Presence of this feature
0: Not Available 1: Available
----- [1 ... 30] Reserved
Enable
(Read / write)
[31] Enable / Disable this feature
0: Disable 1: Enable
4 In Depth Inq
(Read only)
[0 ... 15] Bit depth of the pixel data reported by the
sensor.
Out Depth Inq
(Read only)
[16 ... 31] Bit depth of the pixel data transmitted from
the camera.
8 Quadlet 0
(Read / write)
[1 Quadlet] Defines the 8 bit value that will be transmit-
ted from the camera when the 12 bit pixel
value from the sensor is 0.
(The 8 LSBs of the quadlet carry the data
for the field. The 24 MSBs are all zeros.)
12 ... 36 Quadlet 1 ... 7
(Read / write)
[7 Quadlets] Not used. The values written in these qua-
dlets will be ignored.
40 Quadlet 8
(Read / write)
[1 Quadlet] Defines the 8 bit value that will be transmit-
ted from the camera when the 12 bit pixel
value from the sensor is 8.
44 ... 68 Quadlet 9 ... 15
(Read / write)
[7 Quadlets] Not used. The values written in these qua-
dlets will be ignored.
72 Quadlet 16
(Read / write)
[1 Quadlet] Defines the 8 bit value that will be transmit-
ted from the camera when the 12 bit pixel
value from the sensor is 16.
76 ... 100 Quadlet 17 ... 23
(Read / write)
[7 Quadlets] Not used. The values written in these qua-
dlets will be ignored.
104 Quadlet 24
(Read / write)
[1 Quadlet] Defines the 8 bit value that will be transmit-
ted from the camera when the 12 bit pixel
value from the sensor is 16.
••• •
••• •
••• •
16296 Quadlet 4072
(Read / write)
[1 Quadlet] Defines the 8 bit value that will be transmit-
ted from the camera when the 12 bit pixel
value from the sensor is 16.
16300 ... 16324 Quadlet 4073 ... 4079
(Read / write)
[7 Quadlets] Not used. The values written here will be
ignored.
