Smart Features
BASLER A102
f 6-35
DRAFT
Control and Status Register for the Shutter Time Base Feature
Name Shutter Time Base
Address See “Determining the Address of Smart Features CSRs” on page 6-4.
CSR GUID 648BE1DA - A416 - 11D8 - 9B47 - 00105A5BAE55
Position Field Bit Description
0 Presence Inq
(Read only)
[0] Presence of the shutter time base feature
0: Not Available 1: Available
----- [1 ... 30] Reserved
Enable
(Read / write)
[31] Enable / Disable this feature
0: Disable 1: Enable
4 Increment
(Read only)
[0 ... 31] Increment (in seconds) by which the time base field
can be adjusted.
The value in the increment field is a standard IEEE-
754 single precision (32 bit) floating point number.
8Min
(Read only)
[0 ... 31] Minimum value (in seconds) for the time base field.
The value in the min field is a standard IEEE-754
single precision (32 bit) floating point number.
12 Min
(Read only)
[0 ... 31] Maximum value (in seconds) for the time base field.
The value in the max field is a standard IEEE-754
single precision (32 bit) floating point number.
16 Time Base
(Read / write)
[0 ... 31] Sets the shutter time base in seconds.
The time base can range from 0.000015 second to
0.001221 second in increments of 0.000001 sec-
ond.
The value in the time base field is a standard IEEE-
754 single precision (32 bit) floating point number.
Default = 0.000020 second
