Basic Operation & Standard Features
3-22 BASLER A102
f
DRAFT
Example
Assume that your camera is set for Format 7, Mode 0, that your AOI is set for 100 columns wide
and 110 rows high and that your exposure time is set for 12000 µs. Also assume that after making
all camera settings, you check the Packets Per Frame Inquiry register in the control and status
registers for Format 7, Mode 0. You find that the packets per frame with the current settings is 3.
Formula 1:
Max. Frames/s = 64.2
Formula 2:
Max. Frames/s = 2666.7
Formula 3:
Max. Frames/s = 82.1
Formula one returns the lowest value. So in this case, the limiting parameter is the frame readout
time and the maximum frame rate would be 64.2 frames per second.
L
The number of packets per frame depends on the setting of the Format 7, Mode 0
Bytes Per Packet control register. In this example, we assume that the bytes per
packet is set to the maximum. See Sections 3.12.2 and 3.13.2 for more information.
Max Frames/s
1
110 51.2281 µs ×()9941.0 µs+
---------------------------------------------------------------------------------------=
