Basler Camera User Manual

Specifications, Requirements, and Precautions AW00123402000
2 Basler ace USB 3.0
1.2 General Specifications
Specification acA640-90um/uc acA640-120um/uc
Sensor Size
(H x V pixels)
um: 659 x 494
uc: 658 x 492
um: 659 x 494
uc: 658 x 492
Sensor Type Sony ICX424AL/AQ
Progressive scan CCD
Global shutter
Sony ICX618 ALA/AQA
Progressive scan CCD
Global shutter
Optical Size 1/3" 1/4"
Pixel Edge Length (H x V) 7.4 µm x 7.4 µm 5.6 µm x 5.6 µm
Max. Frame Rate
(at full resolution)
100 fps 120 fps
Mono/Color Mono or color
(color models include a Bayer pattern RGB filter on the sensor)
Data Output Type USB 3.0, nominal max. 5 Gbit/s (SuperSpeed)
Pixel Formats Mono Models: Mono 8 Mono 12p
Mono 12
Color Models: Mono 8 RGB 8
Bayer BG 8 BGR 8
Bayer BG 12 YCbCr422_8
Bayer BG 12p
ADC Bit Depth 12 bits
Synchronization Via external trigger signal, via the USB 3.0 port or free run
Exposure Control Via external trigger signal or programmable via the camera API
Camera Power
Requirements
Nominal +5 VDC, compliant with the Universal Serial Bus 3.0 specification, supplied
via the camera’s USB 3.0 port
~ 3.0 W* @ 5 VDC ~ 2.4 W* @ 5 VDC
I/O Lines 1 opto-isolated input line, 1 opto-isolated output line, and 2 direct-coupled GPIO
lines
Lens Adapter C-mount, CS-mount
Size (L x W x H) 29.3 mm x 29 mm x 29 mm (without lens adapter or connectors)
48.2 mm x 29 mm x 29 mm (with lens adapter and connectors)
Weight < 80 g
Conformity CE, UL (in preparation), FCC, GenICam V. 2.x (including PFNC V. 1.x and SFNC V.
2.x), IP30, RoHS, USB3 Vision, USB-IF (in preparation)
Table 1: General Specifications
