5.9.2 Operation as an Input
This section describes the electrical operation of a GPIO line when the line has been set to operate
as an input.
5.9.2.1 Electrical Characteristics
The following I/O supply voltage requirements apply to a direct-coupled GPIO line when the line is
set as an input.
Your application must be able to accept 2 mA (sink current) from the direct-coupled GPIO input line
without exceeding +0.8 VDC, the upper limit of the low status. The current draw for high-level input
current is < 100 µA.
Figure 34 shows the applicable electrical circuit when a GPIO line is set to operate as an input. The
figure is drawn to specifically apply to pin 1 (Line 3) as an example. However, with the necessary
modifications, the figure applies equally to pin 3 (Line 4).
The figure shows, as an example, the use of a TTL or CMOS logic gate in the external circuit. A
different example for an external circuit is shown in Figure 35.
Voltage Significance
+30.0 VDC Absolute maximum; the camera can be damaged when the absolute maximum is
exceeded.
+0 to + 5.0 VDC Recommended input voltage range (the minimum external pull up voltage is 3.3 VDC as
illustrated in Figure 35).
+0 to +0.8 VDC The voltage indicates a logical 0.
> +0.8 to +2.0 VDC Region where the transition threshold occurs; the logical status is not defined in this
region.
> +2.0 VDC The voltage indicates a logical 1.
Table 10: Voltage Requirements for a Direct-coupled GPIO Line Set as an Input
