AW00123402000 Physical Interface
Basler ace USB 3.0 49
5.6 Camera Power
Power must be supplied to the camera via the USB 3.0 cable plugged into the camera’s USB 3.0
Micro-B port.
Power consumption is as shown in the specification tables in Section 1 of this manual.
NOTICE
An incorrect plug can damage the 6-pin I/O connector.
The plug on the cable that you attach to the camera’s 6-pin I/O connector must have 6 female
pins. Using a plug designed for a smaller or a larger number of pins can damage the connector.
Note that direct-coupled GPIO lines have the advantage of working with very short
delays compared to opto-isolated I/O lines.
Note also that the direct-coupled GPIOs are distinctly more susceptible to EMI
than the opto-isolated I/Os.GPIOs and can turn out not to be usable at all under
harsh EMI conditions.
Accordingly, use of the GPIOs in an environment with elevated risk of EMI calls for
taking additional measures like, e.g. using shorter cables
NOTICE
Voltage outside of the specified range can cause damage.
You must supply camera power that complies with the Universal Serial Bus 3.0 specification.
The camera’s nominal operating voltage is +5 VDC, effective at the camera’s connector.
