Basler Camera - Tightening Sequence When Using the M3 Screws

AW00123402000 Specifications, Requirements, and Precautions
Basler ace USB 3.0 27
1.5.2 Tightening Sequence When Using the M3 Screws
1. Tighten the screws for the mounting screw holes (a) in Figure 24.
2. Tighten the screw for mounting screw hole (b) in Figure 24.
Fig. 24: Designations of the Mounting Screw Holes for the M3 Screws.
To tighten the M3 screws:
(a)
(a)
(b)
Bottom
