AW00123402000 Image Acquisition Control
Basler ace USB 3.0 113
For more information about the exposure active output signal, see Section 6.8.1 on page 127.
For more information about the Sensor Readout Time parameter, see Section 6.9 on page 141.
Line 1
Line 2
Line 4
Line 3
Line 5
Line 6
Line 8
Line 7
Line 9
Line 10
Line 11
Line N-2
Line N
Line N-1
Sensor Readout TimeExposure Time
= line exposure
= line readout
Frame Start
Triggered
Fig. 49: Global Shutter
