Basler Camera User Manual

Features AW00123402000
192 Basler ace USB 3.0
With horizontal binning, adjacent pixels from 2 columns, 3 columns, or a maximum of 4 columns are
summed and are reported out of the camera as a single pixel. Figure 79 illustrates horizontal
binning.
You can combine vertical and horizontal binning. This, however, can cause objects to appear
distorted in the image. For more information about possible image distortion due to combined
vertical and horizontal binning, see Section 8.6.3 on page 195.
Horizontal Binning by 2 Horizontal Binning by 3 Horizontal Binning by 4
Fig. 79: Horizontal Binning on Monochrome Cameras

Basler Camera Specifications

General

Category	Security Camera
Brand	Basler
Resolution	Varies by model
Sensor Type	CMOS
Frame Rate	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Interface	GigE, USB 3.0
Lens Mount	C-Mount, CS-Mount
