Table 1-1. Special-Order DGC-500 Controllers
9355400111 F5J0 400 Hz nominal frequency
9355400112 F1J0
9355400127 F5J1
9355400128 F1J1
9355400113 F5J0
cURus recognized for use in
hazardous locations
9355400114 F1J0
9355400129 F5J1
9355400130 F1J1
SPECIFICATIONS
Current Sensing
Accuracy: ±1% of full scale or ±2 A, whichever is greater
Burden: 1 VA
Terminals: P10, P11 (A-phase)
P12, P14 (B-phase)
P15, P17 (C-phase)
1 Ampere Inputs
Continuous Rating: 0.02 to 1.0 A
1 Second Rating: 2 A
5 Ampere Inputs
Continuous Rating: 0.1 to 5.0 A
1 Second Rating: 10 A
Voltage Sensing
Accuracy: ±1% of full scale or ±2 V, whichever is greater
Burden: 1 VA
Range: 12 to 576 V rms, line-to-line
1 Second Rating: 720 V rms
Terminals: P23 (A-phase), P26 (B-phase), P29 (C-phase), P30 (Neutral)
Frequency
Accuracy: ±0.25% of reading or ±0.2 Hz, whichever is greater
Display Range: 4 to 70 Hz
4 to 450 Hz (P/N 3555400111, 9355400112 only)
Contact Sensing
Emergency Stop Input
Type: Normally-closed dry contacts
Terminals: P35, P39
Programmable Inputs (3)
Type: Normally-open dry contacts
Terminals: P2, P21 (Input 1)
P3, P21 (Input 2)
P4, P21 (Input 3)
9355400990 Rev H DGC-500 General Information 1-3
