APPENDIX B
PARAMETERS AND SETTINGS
INTRODUCTION
This appendix lists all DGC-500 parameters along with the setting range/selections for each parameter.
FRONT PANEL ADJUSTABLE PARAMETERS
Table B-1 lists the DGC-500 settings that can be adjusted through the HMI.
Table B-1. HMI Adjustable Settings
Cool-Down Time Delay 0 - 60 min
Date 01/01/2000 - 12/31/2099
Daylight Saving Time On/Off
Engine Maintenance Cycle Hours Pre-Alarm Reset/Normal
LCD Contrast 25 - 75%
Low Fuel Alarm 0 - 100%
Low Fuel Pre-Alarm 10 - 100%
Metric Conversion On/Off
Pre-Crank Time Delay 0 - 30 sec
Pre-Start Contact Status After Disconnect On/Off
Sender Failure Alarm Time 1 - 30 sec
Time 00:00:00 to 23:59:59
ALL PARAMETERS
Table B-2 lists each DGC-500 parameter in alphabetical order. The setting range or nomenclature used
by the HMI and the BESTCOMS interface is listed beside each parameter.
Table B-2. DGC-500 Settings
Parameter Setting Range
Accelerator Position 0 - 100%
Accumulated Engine Runtime 0 - 99,999 hrs, 59 min
Battery Overvoltage Pre-Alarm Enable On or Off
Battery Overvoltage Pre-Alarm Threshold Off, 15 Vdc, or 30 Vdc
Battery Charger Failure Pre-Alarm Enable Off or On
Battery Voltage 12 Vdc or 24 Vdc
CANBus Address 0 - 253
Communication Parity None, Odd, or Even
Communication Baud Rate 1200, 2400, or 9600
Continuous Crank Time 1 - 60 sec
Coolant Temperature Sender Fail Alarm Enable Off or On
Coolant Temperature Sender Fail Alarm Delay 5, 10, 15, 20, 25, or 30 min
Crank Disconnect Limit 10 - 100%
Cranking Style Continuous or Cycle
9355400990 Rev H DGC-500 Parameters and Settings B-1
