Programmable
Two programmable outputs (PROGRAM OUTPUT1, 2) can be user-configured to close for a variety of
conditions.
Either programmable output can be programmed to close during any of the following operating conditions.
Cooldown timer active
EPS supplying load
Pre-start condition in effect
Switch not in Auto
Programmable Input 1 closed
Programmable Input 2 closed
Programmable Input 3 closed
Either of the programmable outputs can be configured to give a pre-alarm indication by closing during any
of the following pre-alarm conditions.
Battery charger failure
Battery overvoltage
Fuel leak
Fuel leak/sender failure
High coolant temperature
Low battery voltage
Low coolant level
Low coolant temperature
Low fuel
Low oil pressure
Scheduled maintenance due
Weak battery voltage
Either of the programmable outputs can be configured to give an alarm indication by closing during any of
the following alarm conditions.
Battery charger
Coolant temperature sender failure
Emergency stop
Fuel leak
High coolant temperature
Loss of voltage sender failure
Low coolant level
Low fuel
Low oil pressure
MPU speed sender failure
Oil pressure sender failure
Overcrank
Overspeed
SOFTWARE OPERATION
Embedded software controls all aspects of DGC-500 operation. DGC-500 software controls power-up
initiation, HMI configuration, engine cranking, contact input monitoring, fault detection and annunciation,
system parameter monitoring, output contact control, and communication.
Power-Up Sequence
When battery power is applied, the DGC-500 initiates a power-up sequence. During power-up, DGC-500
memory is checked and the LCD displays the embedded software version followed by a prompt to set the
real-time clock. Then, all configuration data stored in nonvolatile EEPROM (electronically erasable
programmable read-only memory) is brought into main memory and the DGC-500 begins operating in
Normal mode. When operating in Normal mode, all enabled functions are active and all inputs are
monitored.
Cranking
The DGC-500 can be programmed for either continuous engine cranking or cycle engine cranking.
NOTE
The run-time counter and maintenance timer values are updated in volatile
memory once per minute. Updated values are saved to nonvolatile memory when
the Auto/Off/Run mode of operation is changed. Additionally, while the engine is
running, the run-time counter value is saved to nonvolatile memory every 15
minutes. If the battery power source fails during DGC-500 operation, these
values are not updated and the changes made after the last save operation to
nonvolatile memory are irretrievably lost.
3-8 DGC-500 Functional Description 9355400990 Rev H
