Table 3-2. Engine Configuration Parameters Obtained from CAN Interface
Engine Configuration Parameter
Metric
Units
English
Units
Update
Rate
Decimal
Place
SPN †
Engine speed at idle point 1 rpm rpm 5 s none 188
Percent torque at idle point 1 % % 5 s none 539
Engine speed at point 2 rpm rpm 5 s none 528
Percent torque at point 2 % % 5 s none 540
Engine speed at point 3 rpm rpm 5 s none 529
Percent torque at point 3 % % 5 s none 541
Engine speed at point 4 rpm rpm 5 s none 530
Percent torque at point 4 % % 5 s none 542
Engine speed at point 5 rpm rpm 5 s none 531
Percent torque at point 5 % % 5 s none 543
Engine speed at high idle point 6 rpm rpm 5 s none 532
Gain (KP) of endspeed governor %/rpm %/rpm 5 s 100
th
545
Reference engine torque Nm ft-lb 5 s none 544
Maximum momentary engine override
speed point 7
rpm rpm 5 s none 533
Maximum momentary engine override
time limit
seconds seconds 5 s 10
th
534
Requested speed control range lower
limit
rpm rpm 5 s none 535
Requested speed control range upper
limit
rpm rpm 5 s none 536
Requested torque control range lower
limit
% % 5 s none 537
Requested torque control range
upper limit
% % 5 s none 538
∗ Press the Select pushbutton to enter the Engine Configuration submenu. Press the Previous
pushbutton to exit the submenu.
† SPN is Suspect Parameter Number.
Diagnostic Trouble Codes (DTCs)
The DGC-500 obtains the diagnostics condition of the transmitting electronic components. The DGC-500
will receive an unsolicited message of a currently active diagnostic trouble code (DTC). Previously active
DTCs are available upon request. Active and previously active DTCs can be cleared on request. Table 3-
3 lists the diagnostic information that the DGC-500 obtains over the CAN interface.
CAUTION
When the CAN interface is enabled, the DGC-500 will ignore the following sender
inputs: oil pressure, coolant temperature, and magnetic pickup.
3-6 DGC-500 Functional Description 9355400990 Rev H
