Menu 1
DGC-500 pre-alarms and alarms are viewed and configured in Menu 1. Figure 3-9 illustrates the Menu 1
screens.
Menu 2
System configuration settings are viewed and configured in Menu 2. Figure 3-10 illustrates the Menu 2
screens.
Menu 3
DGC-500 calibration, transformer ratios, and transducer failure alarms, are viewed and configured in
Menu 3. Figure 3-11 illustrates the Menu 3 screens. The menu screens associated with the calibration
process are illustrated in Section 5, Installation, Calibration.
Menu 4
Engine cool-down time and cranking parameters are viewed and configured in Menu 4. Figure 3-12
illustrates the Menu 4 screens.
Menu 5
Real-time clock settings are viewed and set in Menu 5. Figure 3-13 illustrates the Menu 5 screens.
Exiting Menu Mode
Pressing the Display Toggle pushbutton exits the Menu mode from any level and branch. When the
Display Toggle pushbutton is used to exit Menu mode, the user’s place within the menu tree is saved.
The display will return to the same screen the next time that Menu mode is entered. If the Display Toggle
pushbutton is pressed before a new setting is saved, the existing setting is retained.
Using the Previous pushbutton to back out of Menu mode ensures that the top-level Menu mode screen
is viewed the next time Menu mode is entered.
Sleep Mode
Sleep mode serves as a power saving feature. If the DGC-500 is in Off mode for more than 15 minutes,
the front panel LEDs, LCD, and LCD backlight are turned off. The DGC-500 resumes normal display
operation when any front panel button is pressed or the genset is started remotely via the ATS input. If
needed, Sleep mode can be permanently disabled via BESTCOMS. Refer to Section 4, BESTCOMS
Software for more information.
3-20 DGC-500 Functional Description 9355400990 Rev H
