Bauer Compact-Line JUNIOR II-B - Page 32

1
3
9
8
6
2
7
4
5
10
Fig. 5 Structure, version with petrol engine
1 Exhaust 5 Pull starter 9 Suction filter
2 Air filter 6 Automatic condensate drain 10 Filling valve with final pressure
gauge
3 Tank 7 Carrying handle
4 Choke 8 Safety valve
3 | Product description OPERATING MANUAL
32/106
A_Compact-Line_002_en
10-10-2016
