1
3
9
8
2
7
4
5
6
10
11
12
Fig. 6 Structure, version with petrol engine, view from the rear
1 Final pressure safety valve 5 Condensate drain valve, second
stage
9 Filter system
2 Condensate separator 6 Pressure retention valve 10 Belt guard
3 Final pressure switch 7 Switch-over valve 11 Filling valve with final pressure
gauge
4 Condensate drain valve, last
stage
8 Final pressure safety valve on
the changeover device
12 Exhaust
