Function
Suction
The medium or gas mixture to be compressed is directed to the compressor via the
suction section.
Compression
In the compressor block, the medium is compressed up to its final pressure. Paral-
lel to the compression process, the medium is pre-cleaned using a separator and
cooled using heat exchangers.
Filtration
The filter system is used for the final cleaning of compressed gas mixture.
Distribution
Filling fittings are used to distribute the prepared gas mixture. The consumers are
connected to the compressor unit using special valves and filling couplings.
Drive
The motor drives the compressor using a V-belt.
Water removal
The automatic condensate drain regularly drains the separators and directs the ac-
cumulated condensate of water and oil into a collection vessel.
Control unit
The electric control system monitors and controls the operation of the compressor
unit.
