5 Installation
5.1 General safety instructions
n
Assembly, mounting, and calibration of the sensor may only be performed by a specialist.
n
Only use the appropriate fasteners and mounting accessories intended for installation.
n
Do not use any unassigned output. Unused wires of cable outputs must be insulated.
n
Do not go below the permissible cable bending radii.
n
Prior to electrical connection of the product, the system must be down and not live.
n
Use shielded cables as protection against electromagnetic interference.
n
Cable dielectric strength must at least correspond to the operating voltage.
n
The selected minimum cable cross-section must match the maximum current.
n
The cable temperature resistance must be within the specified device temperature range.
n
Where plug-in connections are added to shielded cables by the customer, these plug-in con-
nections must be EMC compliant and the cable shield must be attached to the connector
housing over a large surface area.
5.2 General information for mounting
n
The device can be operated in any installation position.
n
Mount the device using the provided M3 threads.
n
Align the device in a way the image center is focused on the object under verification.
n
Make sure when installed the device will be exposed to as few vibrations as possible during
operation to prevent impaired image quality (blurred images).
n
When installing the device, make sure there are no obstacles between sensor and object
which may block sensing or create reflections.
n
Make sure the installation location offers maximum protection against dust.
n
Power supply is via the electrical connection (12-pin M12 connecter, A-encoding, male).
n
The USB interface is intended for data transfer only, not for power supply. Power supply al-
ways via the 12-pin M12 connector.
INFO
For sensor attachment please use the specialized mounting material available. This allows sen-
sor installation even at profiles and rods.
