8.2.4 Footer
The footer is found at the bottom of the user interface. The footer is always visible, no matter of
the currently applied mode.
Measurement Rate
n
Display of current measuring rate (in fps). In continuous image
acquisition, the measurement rate is limited by the decoding
time required per image.
Decoding Rate
n
Display images with identified code / total images
n
Display counts up to 4,294,967,296 (2
32
) and then resets to 0.
Alarm
n
Display of an alarm message. Triggers may be:
▪ Excess temperature
▪ Communication error
Result
n
Display of overall result
n
Red: Overall result is Fail
n
Green: Overall result is Pass
Outputs
n
Digital output status.
NOTE: The symbol color does not change, regardless if the
switching output is busy at that very moment.
Communication: Digital output [}59]
n
Yellow: digital output enabled.
n
Gray: digital output disabled.
8.2.5 Visualisation area
The measured data is displayed in the visualisation area. The style and structure of the visuali-
sation area depend on the currently active mode of the web interface.
