Baumer Web interface | 8
V1.0 | IDC200 Operating Manual 41
8.2.2 Menu bar
The menu bar allows the navigation among the modes of the web interface. The currently se-
lected menu item is highlighted by a blue ribbon and blue text.
Monitoring
n
Measured value display.
n
No parameter change enabled.
Parametrization
n
Sensor parameterization.
n
Access to this mode can be optionally protected by password
in Device Configuration.
− Tools Parametrization
n
Image: Manual setting of image and lighting parameters such
as trigger, exposure, lighting and focus.
n
Tools : Manual interference on code reading parameters as
post parameterization or after Auto Setup.
n
Auto Setup: Automatic setting of image parameters, such as
exposure time and focus (if selected). Codes within the sen-
sor's field of view are automatically detected.
n
Tool: Adding new measurement tasks and related auxiliary
tasks.
INFO: A maximum of 8 tools can be parameterized.
− Communication
Parametrization
n
Configuration of the data telegrams to the PLC.
n
Sensor digital outputs settings.
− Jobs
n
Save configured test tasks in a job. Specify which job is to be
executed at sensor start. Import and export jobs.
Device Configuration
n
Setting and retrieving of sensor-specific features and informa-
tion, network settings, time synchronization, process interface
settings, defining password, retrieving settings of web inter-
face and firmware.
Condition Monitoring
n
Display of diagnostic data, such as operating time, tempera-
ture and operating voltage.
8.2.3 Parametrisation area
The parameterization section allows for setting various parameters according to the selected
menu item in Parametrization mode.
