Baumer IDC200 - Auxiliary Tool: Code Check

8 | Web interface Baumer
52 Operating Manual IDC200 | V1.0
Output value Data type Measurement range Description
Code Text - Read code
Code Typ Text see above Read code type
Quality Text - -
CenterX Integer - Code center in X direc-
tion
CenterY Integer - Code center in Y direc-
tion
Orientation Float-Point - Angular range
8.4.1.4 Auxiliary tool: Code check
Measuring tool enables comparison of two values by two input sources. Codes read by the sen-
sor as well as an individually expected value can be selected as input sources.
Auxiliary Tool Compari-
son
NOTE: Auxiliary tools can only use previously parameterized
measuring tools as input source.
n
Input source 1: Selection of first input source. Selection en-
abled if measuring tool has been parameterized.
n
Comparison type: Definition of a comparison criterion for
both input sources.
▪ is equal
▪ is not equal
▪ contains
▪ not contains
▪ begins with
▪ not begins with
▪ ends with
▪ not ends with
n
Input source 2: Selection of second input source. Selection
enabled if measuring tool has been parameterized.
Compare value
n
Definition of the expected value. Default value entry may use
the following formats:
▪ ANSI
▪ Raw data (Hex)
▪ UTF8
The process interface allows for setting the following values:
Input value Data type Measurement range Unit
Comparison type Text IsEqual
IsNotEqual
Contains
NotContains
BeginsWith
NotBeginsWith
EndsWith
-
