Auto: Attempt of reading the code like a book (line by line
from top to bottom or from left to right within a line). Unlike
function, Left > Right / Top > Down it considers the alignment
of all codes. Hence, any twist or slight offset in height will not
effect the sorted output.
Parameter Set
n
Setting the robustness of the code detection.
▪ Standard
▪ Robust
▪ Maximum
NOTE: Enabling this function will increase calculation time!
The process interface allows for setting the following values:
Input value Data type Measurement range Unit
EnableTimeout Bool 0 / 1 -
Maximum number of
codes
Integer 1 - 10 -
Presets Text Standard
Robust
Maximum
-
Quality Text ISO/IEC 15415 -
Sorting Text Disabled
AutoLeftRightTopDown
LeftRightTopDown
LeftRightDownTop
RightLeftTopDown
RightLeftDownTop
TopDownLeftRight
TopDownRightLeft
DownTopLeftRight
DownTopRightLeft
-
Timeout Integer 1 - 2000 ms
TypeGS1 Text GS1 DataMatrix
GS1 QR Code
GS1 Aztec Code
GS1 DotCode
-
TypesOthers Text Data Matrix ECC 200
QR Cod
Micro QR Code
Aztec Code
DotCode
PDF417
-
The process interface is capable of reading the following values:
