Output value Data type Measurement range Description
Code Typ Text see above Read code type
Quality Text - -
CenterX Integer - Code center in X direc-
tion
CenterY Integer - Code center in Y direc-
tion
Orientation Float-Point - Angular range
8.4.1.3 Measuring tool: Matrix code
This tool is for reading matrix codes. Furthermore, the code reading quality can be specified
compliant to ISO/IEC 15415.
INFO
Where it comes to reading several matrix codes of different types, individually parameterized
tools may speed up things.
Image source
n
Image 1
Code types
n
All: image is searched for all readable matrix codes.
n
List: Shows a list of matrix codes for selection.
▪ GS1: Shows a list of GS1 codes.
▪ Misc: Shows the list of codes that are not GS1 codes.
NOTE : Specifying a code type will reduce error identifiers
and processing time.
Number of codes
n
Defines the maximum number of codes to be read in an im-
age.
NOTE: Setting more codes than are available in the image will
increase processing time! Therefore, defining a region for
evaluation makes sense.
Quality
n
Code quality checks enabled / disabled compliant to ISO/IEC
15416.
NOTE: Quality checks are only performed if the code with its
light margin is completely visible in the image, otherwise F is
output even if the code content is readable. Enabling this
function will increase processing time!
Region of Interest Limits
n
Defining a region for evaluation in the image. Only this region
is searched for the code. Truncated code is being fully read, if
possible.
Timeout
n
Limits the calculation time for code identification in ms.
NOTE: Exceeding the defined calculation time will abort the
reading operation. This may either implicate reading of fewer
codes than present in the image or not executing any quality
check.
Sorting
n
Defines the reading direction in an image. This allows for
sorted output if multiple codes are present on the image.
