8.4.2.2 Communication: Digital output
In mode Digital Output, you can allocate the sensor outputs the corresponding actions. At left,
each output has its own panel.
INFO
Settings for Digital Inputs are performed in menu item Device Configuration.
Switching output
n
Select output assignment.
Disabled
Pass: is output if all measurement results are pass.
Fail: is output if a measurement result is Fail.
Result Valid: is output when all other results were output by
the remaining outputs. This allows for controlling the point in
time of result acquisition, e.g. by PLC. Duration should infe-
rior to the Duration of the other outputs.
Trigger Ready: is output if device is ready for another trig-
ger.
Alarm: is output in the event of an alarm.
Device Ready: is output when device is ready for operation
after startup. The output remains permanently active.
Measuring tool: Pass
Measuring tool: Fail
Limit output duration
n
Activation/deactivation of limited output time.
Duration: Output time of the selected signal in ms.
Polarity
n
Select output polarity (output level).
Active High
Active Low
8.4.3 Job mode
Job mode is for job management at the sensor. Up to 32 jobs can be stored on the sensor. Fur-
thermore, the job to be executed at start up can be defined.
There is also the option to export and import all jobs in one file.
Import/export
n
Start with Setup: Selects the job to be executed at startup.
NOTE: Sensor start up is with the job defined here. When
working with a PLC, the PLC may envisage another job at
startup. In this case, create a job with only the image set-
tings (trigger mode: single measurement).
n
Import / Export: Import / Export all jobs in one file. Exter-
nal saving is a file including the packed and encoded jobs.
This file can be imported if the sensors are identical.
Save as Job Setup
n
Save: Saves current job to the next free memory location
(1 - 32). In parallel, this job will be active at sensor startup.
NOTE: Saving to a specific memory location is via the
menu of the desired memory location.
n
Delete all: Delete all saved jobs.
