8 | Web interface Baumer
58 Operating Manual IDC200 | V1.0
Numeric width NOTE: Function only with data encoding ASCII available.
Enable / disable fix number width.
n
Global width: Number selection (0-16).
n
Padding: If the value to be transmitted is inferior to the
defined Global width, remaining space is filled by the se-
lected characters.
▪ Zero ("0")
▪ Empty space (" ")
n
Alignment: Position of the value to be transferred within
the number.
▪ left aligned
▪ right aligned (only with selected Padding Empty
space (" ")
Text width
n
Padding: Specify one filling character.
n
Alignment: Position of the value to be transmitted within
the text.
▪ left aligned
▪ right aligned
NOTE: Setting Local width is in the data block of the data
telegram!
Preview: Preview of Data Telegram as human readable text.
Data: Preview of Data in hexadecimal.
Length: Length Data Telegram in bytes.
NOTE: If TCP protocol is applied,Data Telegram must not exceed 4096
bytes.
Applied PROFINET protocol allows for a length of 8 - 240 bytes, ac-
cording to PLC configuration.
