Baumer Web interface | 8
V1.0 | IDC200 Operating Manual 61
Process Interface Enable/disable process interfaces. If disabled, the sensor will no
longer respond to requests transmitted via this protocol.
n
Protocol:
▪ TCP: Aktivieren / Deaktivieren. Setting of communication pa-
rameters (Port, Receive Timeout, Alive Timeout).
▪ Profinet IO: Enable / Disable Sensor integration into PLC
projects requires installing a product specific driver (GSD
file). This file is available straight by the device.
▪ USB-HID: Enable / Disable. The device will act as keyboard.
The configured Data Telegram is output via the USB inter-
face and can be evaluated by a connected system like a
keyboard entry. Setting of Keyboard layout (German/Eng-
lish). Select point in time for data output. After a result
change (changed successfully read code) or All read codes.
Furthermore, a waiting time in ms can be set, defining the
waiting time prior to output of the next result.
INFO: Once saved on the sensor, connection to the de-
vice web interface via USB is no longer possible.
INFO: After sensor restart, it may take some time until
the connected system (e.g. PC) has fully established the
sensor's HID keyboard. Therefore, the PC will not re-
ceive resp. ignore any data telegrams transmitted dur-
ing this time.
Digital Inputs Sensor digital input settings.
n
Input switch: Setting the respective input function
▪ Disabled
▪ Trigger
▪ Select Job (Switchover only in mode Monitoring)
n
Polarity: Polarity settings of the respective input.
System
n
Security
n
Password Protection: Enable / disable password protection
for Parametrization mode .
n
Backup & Restore: Complete sensor backup respectively re-
store, including jobs and firmware.
n
Web Interface: : Show version of web interface software / li-
censes, and firmware-independent updates. Upload of more
recent firmware revisions to the sensor is feasible, provided
compatibility is not excluded by release notes.
Also possible is Downgrade. However, only up to the revision
with which the sensor was delivered.
n
Firmware: Display version of firmware, as well as update
n
Upload image: Uploads firmware and web interface on the
sensor.
Upload of more recent firmware revisions are possible, pro-
vided compatibility is not excluded by release notes.
Also possible is Downgrade. However, only down to the
firmware revision the sensor was supplied with.
