1 Overview of the Device
1 - 4 Infusomat® compact
plus
P 1.0
EN
For internal use, only
Fig. 1 - 3 Block diagram Infusomat® compact
plus
P
Housing upper part
Accessory Connector
4 wires
Display Board with Display
Signal LEDs Piezo Buzzer
TFT-LCD 320x240
X2
X3
Mainboard
(Processor Board)
Connector Loudspeaker
Connector
Battery
Connector
Accessories
X8
Connector
Keypad / Display
X1
Connector
Sensors / Actuators
Interface
(not in use)
Keypad
(Integrated in Housing upper part)
PCB Sensors
Housing lower part
Power Supply
Inlet Connector
SHK
Peristaltic mechanism
Air sensor
X8
Pump mechanism
X3
X5
Connector
Power Supply
X11
3 wires
X3
3 wires
X7
Battery Module
a
=
X5
X7
PCB SHK
(part of SHK)
Downstream
pressure
sensor
X1 X6 X2
X4
Upstream
pressure
sensor
Pump
door
sensor
PCB Encoder
Connector
Stepper Motor
X10
Stepper
motor
M
Linear
stepper
motor
M
X9
