Infusomat® compact
plus
P 1.0 4 - 1
EN
For internal use, only
4 Check after Repair
Depending on the repairs carried out, the relevant tests of the
checklist for check after repair must be performed
(see "Checklist
for Check after Repair" ➡ p. 4 - 4).
For assignment of tests to repair tasks, refer to table 4 - 1.
If several servicing activities have been carried out, the total of all
necessary tests (checks) has to be performed.
CHECK AFTER REPAIR MATRIX Tests depending on the repair task performed
Repair task performed
T1 Visual Inspection
T2 Electrical Safety
T3 Mechanical Inspection
T4 Operational Test
T5 Pressure cut-off, electronic
T6 Pressure limitation, mechanical
T7 SHK
T8 Second clamp
T9 Delivery accuracy
T10 Air sensor
T11 Temperature sensor
T12 Staff call test
3.1 Housing foot X X
3.2 Gasket for rubber connector X X
3.3 Membrane X X X X
3.4 Pole clamp X X
3.5 Battery module X X X X X X X X X X X
3.6 Second clamp X X X X X X X X X X
3.7 Pump door
3.8 Opening/closing the unit
3.9 Loudspeaker The complete check after repair has to
be performed whenever the pump
door has been removed.
3.10 Processor board
3.11 Accessory connector
3.12 Display board with display
3.13 Housing, upper part
3.14 Housing front
3.15 Pump
3.16 Power supply
Table 4 - 1
NOTICE
If the Pump ICP (see "Spare Parts List" ➡ p. 9 - 1) has been
replaced, run-in the drive before performing the checks after
repair
/ TSC (see "Pump RUN IN" ➡ p. 4 - 2).
