Infusomat® compact
plus
P 1.0 9 - 1
EN
For internal use, only
9 Spare Parts List
Designation Order - No. BN
*
Small parts ICP . . . . . . . . . . . . . . . . . . . . . . . . . . 34522210
with:
Cylinder screw M4x16 ISO 14580 A2 (40 Pcs)
Delta PT screw WN5451 25x6 (10 Pcs)
Delta PT screw A2 WN5454 30x9 (10 Pcs)
Delta PT screw 22x8 WN5451 (4 Pcs)
Delta PT screw A2 WN5452 30x10 (20 Pcs)
Delta PT screw 35x10 WN5451 (10 Pcs)
Delta PT screw 30x8 WN 5451 (10 Pcs)
Cover cap poleclamp (40 Pcs)
Cover cap housing (100 Pcs)
Cover cap drive head (5 Pcs)
Foot (10 Pcs)
Magnet 7x7x3 (5 Pcs)
Hexagon nut M8,5x1 DIN 934 (2 Pcs)
Speaker flap
Lock screw (5 Pcs)
O-Ring 12x3 NBR 50 Shore (5 Pcs)
Seal ring 3x1 50 ShoreA Silicon red (5 Pcs)
Coil valve mechanics (5 Pcs)
Fixing plate (3 Pcs)
Sealing pole clamp (3 Pcs)
IR-LED 100 mA OSRAM IRL 81 A (2 Pcs)
Hall sensor A3212EUA-T (2 Pcs)
Optical sensor (TSL254R) (2 Pcs)
Halkey-Robt.Swabable T-port (PC) 245454024 (2 Pcs)
Designation Order - No. BN
*
Cover cap set CP . . . . . . . . . . . . . . . . . . . . . . . . . 34774501
with:
Cover cap housing (500 Pcs)
Cover cap Pole Clamp (150 Pcs)
Cover cap drive head (70 Pcs)
O-ring 12x3 NBR 50 Shore (5 Pcs)
Lock screw (5 Pcs)
Ribbon cable sensors PCB ICP . . . . . . . . . . . . . . 34774507
Ribbon cable pressure sensor ICP . . . . . . . . . . .34774508
Ribbon cable air sensor ICP . . . . . . . . . . . . . . . .34774509
Ribbon cable display CP . . . . . . . . . . . . . . . . . . . 34774502
ESD wire ICP . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34774510
Loctite 243 . . . . . . . . . . . . . . . . . . . . . Individual purchase
High Vaccum grease . . . . . . . . . . . . . . . . . . . . . . 34507930
* Sets containing spare parts with batch number (BN). Refer to the packaging labels. Documentation of batch numbers of spare part and affected medical device required.
NOTICE
The content of service kits may vary based on experience from
repairs during the product life cycle.
4
