bbraun Infusomat Compactplus P - Page 82

(Master – to be added to the documentation)
Sheet 2 of 3
6 Technical Safety Check (TSC)
EN
6 - 2 Infusomat® compact
plus
P 1.0
For internal use, only
Visual Inspection Electrical Safety
According to IEC 62353
Functional Inspection
Pressure cut-off, electronic:
Delivery rate: 250 ml/h
❒ Upstream
❒ Alarm
❒ Downstream
❒ Pressure stage 5
(0.1 … 0.7 bar) _____ bar
(or 1.5 … 10 psi) _____ psi
❒ Pressure stage 9
(0.7 … 1.3 bar) _____ bar
(or 10 … 19 psi) _____ psi
Pressure limitation, mechanical:
Delivery rate: 250 ml/h
❒ P
max
(2.4 … 4.0 bar) _____ bar
(or 35 … 58 psi) _____ psi
SHK
❒ Is closed after opening the pump door.
❒ P
SHK
(> 0.5 bar) _____ bar
(or > 7.3 psi) _____ psi
Second clamp
❒ Is closed after opening the pump door.
❒ P
2ndClamp
(> 0.5 bar) _____ bar
(or > 7.3 psi) _____ psi
Delivery accuracy
Ambient temperature 20 … 25°C, delivery
rate: 250 ml/h
❒ Divergence (± 5 %) _____ %
Air sensor
❒ Water value
(1100 … 2250 mV) _____ mV
❒ Air alarm
❒ Air value (< 100 mV) _____ mV
Temperature sensor
❒ FuP Temp - KuP Temp
(-1.0 … +1.0 °C) _____ °C
