9 Spare Parts List
Infusomat® compact
plus
P 1.0 9 - 3
EN
For internal use, only
Designation Order - No. SN/BN
*
1 Display board with display CP . . . . . . . . . . . 34522116 . . . . . SN
(devices with serial number 1199 and lower)
2 Housing, upper part ICPP . . . . . . . . . . . . . . . 34522291 . . . . .BN
with keypad (devices with serial number 1199 and lower)
1+2 Housing, upper part ICPP . . . . . . . . . . . . . .34522290 . . . . .BN
with keypad and display
3 Accessory connector CP . . . . . . . . . . . . . . . . 34522002
4 Processor board ICP . . . . . . . . . . . . . . . . . . . 34522201 . . . . . SN
5 Loudspeaker CP . . . . . . . . . . . . . . . . . . . . . . . 34522001 . . . . .BN
6 Pump ICP . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34522206 . . . . . SN
(including stepper motor and encoder PCB)
7 Stepper motor CP . . . . . . . . . . . . . . . . . . . . . 34522107
8 Encoder PCB ICP . . . . . . . . . . . . . . . . . . . . . .34522205 . . . . . SN
9 Pole Clamp complete CP. . . . . . . . . . . . . . . .34522004 . . . . .BN
10 Gasket for rubber connector CP. . . . . . . . . . 34522010 . . . . .BN
11 Power supply CP . . . . . . . . . . . . . . . . . . . . . .34522000 . . . . .BN
12 Battery module CP . . . . . . . . . . . . . . . . . . . .34522005 . . . . .BN
13 Housing, bottom part ICP. . . . . . . . . . . . . . .34522208 . . . . .BN
14 Second clamp ICPP . . . . . . . . . . . . . . . . . . . .34522286 . . . . .BN
15 Pump door ICPP. . . . . . . . . . . . . . . . . . . . . . .34522294 . . . . . SN
16 Membrane ICPP. . . . . . . . . . . . . . . . . . . . . . .34522292 . . . . .BN
17 Air sensor ICP . . . . . . . . . . . . . . . . . . . . . . . .34522204 . . . . . SN
18 SHK ICPP . . . . . . . . . . . . . . . . . . . . . . . . . . . .34522293 . . . . . SN
(including SHK PCB)
19 SHK PCB ICPP . . . . . . . . . . . . . . . . . . . . . . . .34522287 . . . . . SN
20 Pressure sensor ICP . . . . . . . . . . . . . . . . . . . .34522203 . . . . .BN
21 Sensor PCB ICPP . . . . . . . . . . . . . . . . . . . . . .34522288 . . . . . SN
* Spare parts with serial number (SN) or batch number (BN). Documentation of serial/batch numbers of spare part and affected medical device required.
