MX680RD User’s Manual
15
Expansion Slot 1 x Gen 5 PCIe x16 Slot
Watch Dog Timer 1sec ~ 255 sec timer
HW Monitor CPU & System temperature monitoring, Voltages Monitoring
Audio Realtek® ALC888 HD Audio Codec
LAN 2 x Intel® i255-LM 2.5 Gigabit Ethernet Controllers, support 2x
10M/100M/1G/2.5Gbps Ethernet LAN Ports @ rear I/O
GPIO 8 Bit Header
BIOS AMI® UEFI BIOS
AMI BIOS with 256Mb SPI ROM
TPM 1 x TPM 2.0 Security Device (Infineon® TPM Chip SLB9670VQ2.0) or Intel PTT
Onboard I/O Headers
SATA 2 x Std. SATA III Connectors
USB 1 x USB2.0 Header (2 ports on Header)
1 x USB3.2 Gen 1 Header (2 ports on Header with Shroud)
RS232 1 x Locking Type Header
RS232/ RS422/ RS485 1 x Locking Type Header
Front Audio 1 x Header with Shroud
Audio Amplifier 1 x Locking Type Header
Front Panel 1 x Header with Shroud
Fan Header 2 x Headers (12V, 4-pins PWM)
LVDS 1 x Header for LVDS Panel Connection
1 x Locking Type Header for LVDS Panel Backlight Connector
eDP 1 x Header (At bottom side)
SMBus 1 x Header
I2C 1 x Header
GPIO 1 x Header with Shroud
Chassis Intrusion 1 x Locking Type Header
Onboard Jumpers
COM Port Ring-In/ Power Select 1 x Dip Switch provides signal selection of “12V” or “5V” or “Ringin” on 2 COM
ports
AT/ATX Mode Select 1 x Header
Clear CMOS 1 x Header
LVDS PWM Backlight Voltage Select 1 x Header
LVDS Brightness Control Mode Select 1 x Header
