MX680RD User’s Manual
16
Rear I/O Ports
DP (Display Port) 4 x DP Connector
USB 3.2 3 x USB3.2 Gen 2x1 Type-A Connectors (1x Dual Stack, 2x Dual Stack with LAN)
1 x USB3.2 Gen 2x2 Type-C Connector
LAN 2 x 10M/100M/1G/2.5G bps LAN Ports
Audio 1 x Line-Out
1 x Mic-In
DC_IN Connector 1 x DC Power Jack (DIA 5.5mm (Outer), 2.5mm (Inner))
Power & Connector
1 x 4 pin power Connector
1 x DC Power Jack (DIA 5.5mm (Outer), 2.5mm (Inner))
Form Factor
Mini-iTX 6.7” x 6.7” (170mm x 170mm)
