Beckhoff EL72 1-901 Series User Manual

Object description and parameterization
EL72x1-901x212 Version: 1.9
7.2.1 Configuration data
Index 2002 Amplifier Settings
Index (hex) Name Meaning Data type Flags Default
2002:0 Amplifier Settings Maximum subindex UINT8 RO 0x49 (73
dec
)
2002:11 Device type 1: Servo drive (cannot be changed) UINT32 RW 0x00000001 (1
dec
)
2002:12* Current loop integral
time
Integral component of current controller
Unit: 0.1ms
This value is affected by automatic scanning. (see Au-
tomatic scanning of the electronic type plates [}143])
UINT16 RW 0x000A (10
dec
)
2002:13* Current loop proportional
gain
Proportional component of current controller
Unit: 0.1V/A
This value is affected by automatic scanning. (see Au-
tomatic scanning of the electronic type plates [}143])
UINT16 RW 0x0064 (100
dec
)
2002:14 Velocity loop integral
time
Integral component of velocity controller
Unit: 0.1ms
UINT32 RW 0x00000032
(50
dec
)
2002:15 Velocity loop propor-
tional gain
Proportional component of velocity controller
Unit: mA / (rad/s)
UINT32 RW 0x00000096
(150
dec
)
2002:17 Position loop propor-
tional gain
Proportional component position controller
Unit: (rad/s) / rad
UINT32 RW 0x0000000A
(10
dec
)
2002:19 Nominal DC link voltage Nominal DC link voltage
Unit: mV
UINT32 RW 0x0000BB80
(48000
dec
)
2002:1A Min DC link voltage Minimum DC link voltage
Unit: mV
UINT32 RW 0x00001A90
(6800
dec
)
2002:1B Max DC link voltage Maximum DC link voltage
Unit: mV
UINT32 RW 0x0000EA60
(60000
dec
)
2002:29 Amplifier I2T warn level I²T model warning threshold
Unit: %
UINT8 RW 0x50 (80
dec
)
2002:2A Amplifier I2T error level I²T model error threshold
Unit: %
UINT8 RW 0x69 (105
dec
)
2002:2B Amplifier temperature
warn level
Overtemperature warning threshold
Unit: 0.1 °C
UINT16 RW 0x0320 (800
dec
)
2002:2C Amplifier temperature er-
ror level
Overtemperature error threshold
Unit: 0.1 °C
UINT16 RW 0x03E8 (1000
dec
)
2002:31 Velocity limitation Velocity limitation
Unit: rpm
UINT32 RW 0x00040000
(262144
dec
)
2002:32 Short circuit brake dura-
tion max
Max. duration of armature short circuit brake
Unit: ms
UINT16 RW 0x03E8 (1000
dec
)
2002:33 Stand still window Standstill window
Unit: rpm
UINT16 RW 0x0000 (0
dec
)
2002:41 Low-pass filter frequency Low-pass filter frequency
Unit: Hz
The following values can be set:
0 Hz = off
160 Hz
320 Hz
UINT16 RW 0x0140 (320
dec
)
2002:49 Halt ramp deceleration Halt ramp deceleration
Unit: 0.1 rad / s²
UINT32 RW 0x0000F570
(62832
dec
)
