89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page 7-25
© Honeywell International Inc. Do not copy without express permission of Honeywell.
SPR Flag (LAT/VRT Super Flag)
Selection Description
Hidden The lateral and vertical flag on the external indicator is hidden
In view The lateral and vertical flag on the external indicator is in view
Table 106 NAV Superflag Test Page
TO-FROM
Selection Description
FROM The FROM flag on the external indicator is in view
Hidden The TO/FROM flag on the external indicator is hidden
TO The TO flag on the external indicator is in view
Table 107 Navigation TO/FROM Page
Selected Course
This section will calibrate the external CDI/HSI to the AeroNav XXX.
1. Select 150° on the CDI/HSI;*
2. Verify the Selected Course is displayed on the AeroNav 880/900 and press the ENTR button
on the AeroNav XXX;
3. After calibrating, verify 30° increments on the CDI/HSI are properly displayed on the
AeroNav XXX ±2°.
* In order to do the OBS calibration on a KI208A or KI209A, you have to toggle to the “Main
Discrete I/O” page and turn on the GPS discrete toggle. Then turn to the Main CDI/OBS
config page (without toggling back to the Discrete I/O page) and calibrate the OBS by dialing
150 degrees on the indicator
DME Channel Mode
This configuration allows you to set the format for the DME tuning data output.
Selection Description
UNINSTALLED No DME installed/configured
King Serial King Serial DME tuning
Parallel 2x5 2 of 5 parallel DME tuning
Parallel BCD Shifted BCD (Binary Coded Decimal) parallel DME tuning
Parallel Slip Slip-code parallel DME tuning
Narco 890/891 2 of 5 parallel DME tuning, compatible with the following DME units:
Narco DME 890
Narco DME 891
ARC (Cessna) RTA-476A
Table 108 DME Channel Mode
