Category Vendor Model
Narco
Not specified
Pointer
3000
Kannad
Not specified
Radar
Bendix King
RDR 2000 *
UAT
Avidyne
Skytrax100 (formerly MLB100)
Avidyne
SkyTrax100B*
Freeflight Systems
FDL-978-RX**
Garmin
GDL 88**
* AeroNav Software version 10.2 or higher
** AeroNav Software version 10.2.1 or higher
*** Compatibility with P/N 011-00986-00 or 011-00987-00 only pre software 10.2.3.1. With
software 10.2.3.1 or higher P/N 011-03177-X0 will function
Table 31 AeroNav XXX Compatible Equipment
2.4 Minimum System Configuration for VFR
2.4.1 VFR Installation
This section is intended for stand-alone AeroNav XXX installations intended for VFR navigation.
The following items must be installed in AeroNav XXX VFR Configuration:
• AeroNav 880/900 or AeroNav 780/800 unit
• GPS Antenna (TSO-C144a or TSO-C190, See Section 3.3.5 Table 34 for
approved antennas)
• VHF Communication Antenna is needed for communication functions (N/A
for AeroNav 880/780)
• VHF Navigation Antenna is needed for VOR functions (N/A for AeroNav
880/780)
All VFR installations must install a “GPS APPROVED FOR VFR USE ONLY” placard.
All VFR installations, as described in this Section, are considered a minor alteration when installed on
a no-hazard basis to supplement VFR navigation.
