89000046-014 KSN 780/8XX/900 AeroNav AML STC Installation Manual for Helicopters
Rev 0 Page 1-3
© Honeywell International Inc. Do not copy without express permission of Honeywell.
1.3 Unit Modifications
The following tables list the hardware modifications since initial release of the AeroNav 900 and
AeroNav 800. The AeroNav 880 and AeroNav 780 do not have any unit modifications at the time of
this revision.
Modification Change Hardware PN Hardware
Revision
Software HW Release
Date
MOD 20
ADDS SHIELDING TO VHF
CIRCUITS TO ELIMINATE
SQUELCH BREAK
700-00182-700
700-00182-701
700-00182-720
700-00182-721
11
11
11
11
10.1 or later 08/04/2019
Table 3 AeroNav 900 Modification History
Modification Change Hardware PN Hardware
Revision
Software HW Release
Date
MOD 20
ADDS SHIELDING TO VHF
CIRCUITS TO ELIMINATE
SQUELCH BREAK
700-00179-700 03
03
10.1 or later 08/04/2019
Table 4 I AeroNav 800 Modification History
1.4 Technical Specifications
This section gives mechanical and electrical characteristics for the AeroNav 880/900 and AeroNav
780/800.
1.4.1 AeroNav 880/900 Specifications
The AeroNav 880/900 unit has the following characteristics:
1.4.1.1 AeroNav 880/900 Physical and Electrical Specifications
Physical Specifications
Bezel Height 4.58 inches (116 mm)
Bezel Width 6.25 inches (159 mm)
Depth (w/Connectors) 11.00 inches (279 mm)
Weight See Table 9
Connectors (Aircraft Mating Connector) P1001/P1050 - 78-position High Density D-
Subminiature (male)
P1002- 25-position Standard D- Subminiature
(female)
P1006- 44-position High Density D- Subminiature
(male)
